RFK5
Designed with the real world in mind.
Rear View Camera
Features
- High Resolution CMOS camera
- 2,9 mm focal length
- Power Input: 10-32VDC
- CCIR FBAS video signal
- CAN-Bus interface
- Wide temperature range
- Shock-/Vibration acc. to MIL-STD 810G
RFK5
Overview
These rugged displays come in sizes from 11.6″ to 15.6″ with Full HD resolution and optional high-brightness NVIS backlight. All models share the same layout, electronics, and interfaces, making them easy to scale and integrate. Built to military and defense standards, they offer reliable performance even in tough environments.
Specifications
Camera sensor
- 1/2,8, Sony IMX462LQR, CMOS
- 0,001 Lux at 30 IRE
- 1920 x 1080 Pixel max. resolution
- Readout rate: FHD 1080p mode 120fps
- Readout mode: All-pixel scan mode ; 720p-HD mode
- Shutter: Shutter electronical
- Camera module: CMOS
Objective
- Lens additionally secured against shock and vibration
- 2,9mm focal length, F2; H:114° ; V:80°
Power Supply
Supply voltage: 10…32 VDC
- Power consumption: max. 1.2 Amax
- reverse polarity protection
Power Supply
- Supply voltage: 90…264 VAC via 3pin ICE-Socket
- ON/OFF: 1x Switch
Videosignal
CCIR FBAS 1Vss at 75Ohm
Mounting
Mount: 4x M8
Housing
- Milled aluminium, EN AW-5083
- RAL 6031 F9
- Surface: LN9368-4301.1 T6; DIN50965 Fe/Sn12/T1
- Front screen with EMV-Mesh
- Width: 150 mm (w/o connectors); 174 mm (with connectors)
- Height: 90 mm (w/o connectors); 90 mm (with connectors)
- Depth: 146 mm (w/o connectors); 146 mm (with connectors)
- Weight: approx. 2 kg
CONTROLS & COMMUNICATION
- Communication: CAN
CONNECTOR
VG 95234A-20A48PN
Environmental
- IP66 / IP68 acc. to EN60529
- Operating temperature: -46°C…+63°C
- Storage temperature: -46°C….+71°C
- Schock/Vibration: MIL STD-810G
- Operating height: max. 4500m
