Rugged Modular Video Camera IR
Designed with the real world in mind.
Camera
Features
- High Resolution Cameras with different types of sensors
- Same Design and size for all sensors
- Standard D38999 Interfaces and pinout for all sizes
- Many Different FOV (Field of view) available
- Power Input: 12VDC; 10-36VDC compliant to VG-STD, MIL-STD and DEF-STAN
- EMI: compliant to VG-STD, MIL-STD and DEF-STAN
- Environmental: compliant to VG-STD, MIL-STD and DEF-STAN
- Size and weight optimized rugged design
- Mounting capability for Dual-CAM version
RMVC IR
Overview
These rugged displays come in sizes from 11.6″ to 15.6″ with Full HD resolution and optional high-brightness NVIS backlight. All models share the same layout, electronics, and interfaces, making them easy to scale and integrate. Built to military and defense standards, they offer reliable performance even in tough environments.
Specifications
Day Camera
- Sensor: CMOS (low light)
- Resolution: 1920×1080
- Video-Output: HD-SDI
- FOV: different lenses available
Night Camera
- Sensor: Uncooled Thermal Imager
- Resolution: 1024×768
- Frequency Band: 8-14μm
- Video-Output: CVBS / HD-SDI
- FOV: different lenses available
Power Supply
- Supply voltage: 12 VDC from E-Box
- Power consumption: max. 20W @ 28VDC
MOUNTING
- Mount: 10x M6
HOUSING
- Material: Aluminium Alloy
- Powder coated
- RAL 6031
- Width: 65mm
- Heigth: 70mm
- Depth w/o Connector: 100mm
- Weight: approx. < 1 kg
ENVIRONMENT
- Operating temp.: Acc. to MIL-STD 810
- Humidity: Acc. to MIL-STD 810
- Shock: Acc. to MIL-STD 810
- Vibration: Acc. to MIL-STD 810
- EMC: Acc. to MIL-STD 461
CONTROLS & COMMUNICATION
Communication: COM to E-Box
CONNECTOR
- Connector X1: Combined Input
- Type: D38999
- Video-Output: Coax contact 75Ω Power-Input: Pin (Male) COM-Input Pin (Male)
