Intel® Cedar Trail™ platform, Atom N2600 1.6GHz Dual Core Processor
10.1” Sunlight Readable Display with with Transflective LCD, 2.000 nits
Seamless communication functions, WWAN GPRS/3.5G/4G, GPS Tracker (optional)?
Wide Temperature range -20°C to 50°C
Outdoor viewable application?• Dual cameras support?
RFID (NFC) module support?
More than 12hrs operating time with Dual Batteries in 25°C environment?
Wide coverage accessories to meet different deployment needs?
Certified to MIL-STD-810G and IP65?
Microsoft® WS7E and WS7P support
Lucius & Baer delivers the best functionality and ergonomics for user application. Base on MIL-810G military standard reliability (high temperature, low temperature, shock, vibration, drop), the Fully-Rugged Tablet from Bit pass from -20°C to +50°C, highly transit shock and vibration, 6 feet drop resistant to concrete surface, and also IP65 fully sealed against water & dust damage. With sunlight readable (2.000 nits) touch screen coating technology, fanless thermal conduction design, and expansion flexibility for barcode scanner, MSR , GPS, WWAN, 4G, WIFI, GPS Tracker, RFID or wireless combo communication functions, our LB-RTC 1016 Rugged Tablet can meet most of harsh outdoor environment application and will be the best tool of your job assistance.
LB-RTC is the best choice for the industry professionals.
Intel® Cedar Trail™ Atom N2600 1,6GHz Dual Core Processor
Max. 2GB DDRII 800 Memory Down
32GB 1.8-inch Half-Slim SSD Installed
10.1-inch LED Backlight Screen with 5-wire Resistive Touch
1366 (W) x 768 (H) WXGA / 1280(W x 800(H) WXGA (option)
Transflective plus type (= 2.000nits in direct sunlight)
2 x High Quality Speakers
Wi-Fi IEEE 802.11 b/g/n and Bluetooth 2.1
3,5G or LTE / GPS (Option)
- ISO/IEC 1443A, 1443B, 15693
- Mifare 1K/4K, Ultralight
- NFC-IP1 Protocol
2 Mega-pixel, audio input (Front Bezel)
5Mega-pixel, LED auxiliary light (Rear Bezel)
1 x Compatible with TPM 1.2
1
2
1
1
1
1
1
1
1
4+ Way Navigation button with integrated Enter button
5
2 x Barcode buttons (Programmable)
Power
Storage
Wi-Fi
277.8 (W) x 206 (H) x 26.5 (D) mm
1.2kg (2.65lb)
CE, FCC, UL, VCCI, CCC; CE/FCC SAR
WES 7-WS7E, WES-WS7P
IP65 equivalent
64-ft drop (MIL-STD-810G Method 516.6 Procedure IV)
Operating : 20g, 11ms, Terminal sawtooth.
Non-operating : 40g, 11ms, Terminal sawtooth
-20°C to +50°C (MIL-STD-810G)
-30°C to +70°C( MIL-STD-810G)
5-90% without condensation
Internal Smart Lithium Polymer Battery, 3800mAh
AC 100V ~ 240V, 50~60Hz input; 19VDC@3.42A, 65W
